Every value traced back to the page it came from
Ratings and impedance
Every unit and panel, read against the IEC series.
Loonar takes the distribution transformers, grid units, switchgear and auxiliary supply out of the tender and lays them out tag by tag: rating, HV and LV voltages, vector group, impedance, cooling, tap changer and the IEC standard each one answers to. The bay reference from the single line diagram sits beside the rating, and every value carries its page.
Technical deviations
Sixty-two items become nineteen decisions.
Loonar rolls the values up against your type test evidence, so short-circuit withstand is one row covering the whole 132/33 kV scope rather than a check per unit. A report held for an 8 MVA design and not the 10 MVA, on-load tap changers at twenty-two weeks, a loss penalty you cannot underwrite, cast resin below your smallest frame: each one is a deviation with its items and the register behind it.
Projects › Your Company Ltd.
Deviations & decisionsScope of supply
Full deviation 4Partial deviation 10Missing info 14Compliant 12 Show all 40
All 40 Technical 19 Quality & compliance 11 Logistics 3 Documents 5 Other 2
Technical 19 Product Matching, against the catalogue
RequirementApplies toYou supplyStatus
Short-circuit withstand Type test report to IEC 60076-5 on an identical design 18 of 62 items 132 / 33 kV units Report held for a 8 MVA unit; the 10 MVA design is not covered Type test certificates, short-circuit index Full deviation suggested Cannot be doneCosts extra
Tap changer On-load ±9 × 1.67%, motor driven with AVR interface 18 of 62 items On-load tap changers are bought in, 22-week lead time Supply chain register, OLTC vendors Partial deviation suggested Cannot be doneCosts extra
No-load losses Guaranteed with a penalty of £8,000 per kW exceeded 36 of 62 items We guarantee losses to IEC tolerance but not against a penalty rate Commercial policy, loss guarantees Partial deviation suggested Cannot be doneCosts extra
Vector group Dyn11 for distribution, YNd11 for grid units 44 of 62 items Both vector groups are standard in the offered range Product catalogue, winding configurations Compliant suggested
Impedance on auxiliary units not stated in the RFQ 8 of 62 items Missing We assume 4% to suit the downstream board Ask the client to confirm before we finalise the design Missing info suggested Cannot be doneCosts extra
Internal arc classification IEC 62271-200 IAC AFLR 25 kA / 1 s 14 of 62 items Standard classification for the offered panel range Type test certificates, switchgear index Compliant suggested
Cooling Cast resin AN for the auxiliary transformer 8 of 62 items Cast resin is offered but not below 630 kVA in this voltage class Product catalogue, dry type range Full deviation suggested Cannot be doneCosts extra
